Vertical Machining Centers Have Fast Operating Speed and High Processing Efficiency

Overview
Product Description
Specification
Certifications
Packaging & Shipping
Company Profile
After Sales Service
FAQ

Overview

Basic Info.

Model NO.	VMC855
Application	Metal
Process Usage	Metal-Cutting CNC Machine Tools
Movement Method	Linear Control
Control Method	Semi-Closed Loop Control
Numerical Control	CNC/MNC
Processing Precision	0.01~0.02(mm)
Performance Classification	Mid-Range CNC Machine Tools
Certification	CE, ISO 9001
Condition	New
X/Y/Z Travel	800/550/5500mm
Spindle Nose to Table	120-670mm
Spindle Center to Column	575mm
X/Y/Z Rapid Feed	36/36/32m/Min
Feed Speed	1-8000mm/Min
Table Size	550X1000mm
Max Load	500kg
Spindle Speed	1-8000rpm
Spindle Sleeve Diameter	150mm
Spindle Taper	Bt40
Main Motor	7.5kw
Position Accuracy	0.005mm
Repeat Position Accuracy	0.003mm
Tool Magazine	24t,Disc,Manipulator
System	Siemens/Fanuc/Knd
Transport Package	Plywood Case with Steel Pallet
Specification	VMC
Trademark	XILI / OEM
Origin	China
HS Code	8457101000
Production Capacity	30sets/Month

Packaging & Delivery

Package Size280.00cm * 265.00cm * 225.00cm Package Gross Weight5400.000kg

Product Description

Tengzhou XILI Manufacturer Milling Machine VMC855

1. Resin sand castings, after aging treatment, inside with mesh stiffeners, ensure good stability of structure.

2. 3-axis roller linear guideways, Z-axis designed with six sliding blocks, high speed, high rigidity, low friction, low noise, long service life.

3. 3-axis large pitch ball screws, pre-drawing treatment, good rigidity, good accuracy, high speed.

4. Direct connection structure between servo motors and ball screws, ensures positioning accuracy.

1. Taiwan brand spindle unit, P4 spindle bearings, high speed, high rigidity, good accuracy. 2. Mandatory automatic lubrication system for guideways and ball screws, ensures long service life. 3. Full protection guard, disc type tool magazine are standard.

Specifications of Tengzhou XILI Manufacturer Milling Machine VMC 855

Delivery time: generally 30-45 days production time after confirmation of order

Packing type: machine is covered with damp-proof plastic film, then packed in plywood case (with steel pallet)

Packing size: 2100 x 2200 x 2250mm (L/ W / H), can be delivered in 20GP container

Vertical Machining Centers Have Fast Operating Speed and High Processing Efficiency

We will supply enough spare parts and accessories with our Manual Mill Milling Machine when shipment. Within one year after receiving our manual mill milling machine, If there are any damaged parts or accessoreis, We will supply them to you by air-mail free of charge.

1. What is the MOQ ?
Minimum order quantity is 1 set.

2. What is the payment term ?
Usually we prefer T/T. 30% deposit, 70% balance payment against machine ready to delivery photos and videosOther payment terms are also acceptable after discussion.

3. What is the trade terms ?
Jsually is FOB.
Others like CIF,CFR,EXW...... are also acceptable.

4. How long is the guarantee ?
12 month after machine's delivery from factory.
Within waranty, we guarantee spare parts free of charge and online supports for installation, operation, maintance and trouble shooting etc.

5.What kinds of machines do you supply?
Company specialized in producing CNC & manual milling machines. Include:
CNC gantry machining center
Vertical machining center
Simple NC milling machine

Conventional manual milling machines (Vertical, Horizontal, Universal, Turet mil, Swivel head mil, Power sliding ram type, Bed type,Tool milling machine, Gantry type etc.)

6.How can I believe your company ?
XILI Machine Tool has more than 20 years milling machine production history. covers an area of about 50000 square meters,with 20 million CNY fixed assets and more than 300 employees.

Xili Machine Co.,Ltd. is a ISO9001 company, all products are with CE certificate.

Welcome your inquiry and visiting.

If you need any further information, feel free to contact us.

Product Description

Specification

Items	Unit	VMC1160	VMC855	VMC750
Working area
Table size	mm	1200x600	1000x550	900x500
Max. load of table	kg	800	500	400
T-slot (width x No. x pitch)		5/18/125	5/18/90	3/18/125
Distance from spindle nose to table	mm	120-720	120-670	120-620
Distance from spindle axis to column	mm	650	575	560
Table travel of X axis	mm	1100	800	700
Table travel of Y axis	mm	600	550	500
Headstock travel of Z axis	mm	600	550	500
Spindle
Spindle taper		BT40	BT40	BT40
Spindle diameter	mm	150	150	120
Spindle speed	rpm	8000	8000	8000
Main motor power	kw	11	7.5	5.5
Feed
Feed speed-X/Y/Z	mm/min	1-8000	1-8000	1-12000
Rapid speed-X axis	m/min	24	36	36/48
Rapid speed-Y axis	m/min	24	36	36/48
Rapid speed-Z axis	m/min	20	32	32
Tool magazine
Type		Disc 24T	Disc 24T	Disc 20T
Max tool diameter	mm	80/150,80/130	80/150,80/130	80/150,80/130
Max tool length	mm	300	300	300
Max tool weight	kg	6/7	6/7	6/7
Others
Positioning accuracy	mm	±0.005	±0.005	±0.005
Repeat positioning accuracy	mm	±0.003	±0.003	±0.003
Machine overall dimension (LxWxH)	mm	2900x2400x2800	2640x2180x2600	2640x2180x2450
Net weight	kg	7200	5400	4200

Certifications

Packaging & Shipping

Company Profile

Our factory is located in Tengzhou City, with nearly 20 years history & more than 300employees.Products include:Gantry machining center.VMC machining center,conventional manual mills (vertical, horizontal, universal, knee-type, bed-type, gantry-typeetc.)

The main products have developed to 7 series in recent years: CNC Planer-type machining center CNC vertical machining center,CNC horizontal machining center series,CNC milling machine series,knee-type milling machine series,planer-type milling machine series,single-face milling machine series,vertical drilling machine series,drilling and milling machine series. Altogether there are more 40 specifications. Some products have national patents. In 2002, we passed the ISO9001 quality guarantee system certification, and got the certificate of CE in 2007. lt was awarded Shandong high technology company in 2010.

We are always pursuing the following notions of service and management: "customers first, quality first", "active improvement, winning through innovation", "credit is the basis".

Focusing on talents, we create the future relying on the science and technologies.

Focusing on quality, we rely on the customers to get common development.
